Quickstart and Basic Functions of the Carrier® Infinity
The Carrier® Infinity Touch is the touchscreen wall control installed with Infinity systems, and day to day you only need four things: how to read the screen, how to change the temperature, how to switch between heating and cooling, and how to use the Touch-N-Go comfort settings.
Watch: Your Infinity Touch in 90 Seconds
Try It Yourself : Click the Screen
The Every Day Four
1. Reading the Screen
When it's resting, the screen shows the date and time, your room temperature, and your signal. Tap the screen to wake it: your mode sits in the top-right, the Features button on the left, Touch-N-Go activities below, your room temperature in the center, and your set-point **Heat To** on the right, with a Menu button in the corner.
2. Changing the temperature
Tap the up or down arrows next to **Heat To** your set-point moves with each tap. To hold a temperature yourself, use Touch-N-Go's **Manual** option (step 4).
3. Switching between heat and cool
Tap **mode** in the top-right, then choose Heat, Cool, Auto, or Off. Auto is fine for most St. Louis homes in spring and fall. The system switches itself when our weather can't decide.
4. Touch-N-Go activities
Tap **Select Activity** to pick Home, Away, Sleep, or Wake. Each stores its own temperatures, or choose **Manual** to hold a temperature yourself. Set each activity once and you'll rarely touch the schedule again.
